What a better way to dress up your exterior renders than with this fully parametric outdoor pergola Revit family. The wide array of parameters, like width, depth, clearance height, thickness of columns, thickness of beams, number of middle beams, etc., will allow you to create infinite variations. Ideal for outdoor spaces in residential and commercial projects.
- Parametric: Yes
- Hybrid*: No
- Compatible with: Revit 2016 and higher.
- Family type: Entourage
- Materials/textures: Yes
- Approximate file size: 0.56 MB
- File format: .rfa
This Revit family pergola comes with the following customizable parameters and options:
Width:
- Minimum width: 4′
- Maximum width: 30′
Depth:
- Minimum depth: 4′
- Maximum depth: 40′
Clearance height:
- Minimum clearance height: 5′
- Maximum clearance height: 40′
Thickness of columns and beams:
- Minimum thickness: 4″
- Maximum thickness: minimum value between width/6 and depth/6
Number of middle beams and top beans:
- Minimum number of middle beams: 2
- Maximum number of middle beams: depth/6″
- Minimum number of top beams: 4
- Maximum number of top beams: (width+extra value*2)/6″
Topmost beams can be turned off.
Materials for:
- Wood
* Hybrid families combine native Revit objects with other 3D applications’ objects for a more organic and realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.
All files are delivered in zip format. Before using your 3D models, you will need to unzip the downloadable file using a 3rd party software like Winzip or Peazip. Make sure you have a software to unzip files before purchasing 3D models.
