Modern Revit Railing Family

• Parametric: Yes
• Hybrid*: No
• Compatible with: Revit 2016 and higher.
• Family type: Railings
• Materials/textures: Yes
• Approximate file size: 1.80 MB (actual family size is a lot smaller. This size is for the whole rvt project)
• File format: .rvt

This Modern Revit Railing Family comes with the following customizable parameters and options:

Railing comes in 3 pre-configured heights:

30″
36″
42″

You can find the materials in this Revit railing already configured in the Material Browser. Names of materials:

Modern Railing – Balusters and Details
Modern Railing – Bottom Rail
Modern Railing – Top Rail

To use the Revit railings, open the rvt file, select the three railings, press Ctrl+C, open the drawing you want to use them in and paste them in it+  (Ctrl+V)

+Make sure you click on the screen to insert them. After inserting them, you can delete them. This will add them to the drawing. The materials will follow along (you only have to assign the textures/materials properties in the Material Browser)

IMPORTANT NOTE ABOUT THIS REVIT RAILING FAMILY: Do not use the rvt file of the railing as the starting file to create a new project since it was purged of all other objects to optimize its size.

* Hybrid families combine native Revit objects with other 3D applications’ objects for a more realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.

Before purchasing our Revit families and 3D models, make sure you have a software like Winzip or Peazip to unzip files since you will be provided with zip format files.
