Revit Bed Family With Modern Headboard

Included Files:

This product includes 1 zip file containing:

• Revit Bed family (.rfa)
• Revit Headboard family (.rfa)
• Texture files

Included Elements Inside Each Revit Family:

Revit Headboard Family

• Upholstered headboard
• Headboard legs
• Multiple preset size types

Revit Bed Family

• Mattress
• Box spring
• Bed skirt
• Comforter
• Pillows
• Decorative square cushion
• Multiple preset bed size types

Key Parametric Controls:

Revit Headboard Family

• Adjustable leg height
• Adjustable headboard height
• Adjustable headboard width
• Visibility control for legs
• Material parameters for headboard and legs

Revit Bed Family

• Size selection
• Visibility control for square cushion
• Material parameters for mattress, bed skirt, box spring, and legs
• Editable comforter material in Material Browser
• Editable pillow material in Material Browser
• Editable square cushion material in Material Browser

Revit Headboard Family:

• Parametric: Yes
• Hybrid*: No
• Compatible with: Revit 2016 and higher.
• Family type: Furniture
• Materials/textures: Yes
• Approximate file size: 0.45 MB
• File format: .rfa

Revit Bed Family:

• Parametric: Yes
• Hybrid*: Yes
• Compatible with: Revit 2016 and higher.
• Family type: Furniture
• Materials/textures: Yes
• Approximate file size: 1.28 MB
• File format: .rfa

This Revit Bed Family With Modern Headboard comes with the following customizable parameters and options:

Revit Headboard Family:

Revit headboard comes in three sizes+: king, queen and twin

+Additional sizes can be created in Edit Type

Leg height:

• Min leg height: 8″
• Max leg height: no limit

Headboard height (does not include the legs) in this Revit bed family:

• Min headboard height: 1′
• Max headboard height: no limit

Headboard width:

• Min headboard width: 2′
• Max headboard width: no limit

Legs can be turned off.

This headboard, which is part of the Revit Bed Family With Modern Headboard comes with material parameters for:

• Headboard
• Legs

Revit Bed Family:

Revit bed comes in three sizes++:

• Full Size
• Queen Size
• King Size

++ Sizes different than these pre-configured ones will turn off some objects on the bed and/or might give odd results (oversimplified bed).

You can turn on/off the following parts of the Revit bed family:

• Square Cushion

Part of the materials of this Revit bed can be found in the Properties, while the rest of the materials can be found in the Materials Browser.

Materials in the properties (Material parameters):

• Mattress
• Bed Skirt
• Box Spring
• Legs

This Revit Bed Family With Modern Headboard comes with the following materials (material names) found in the Material Browser:

• Simple Bed – Comforter
• Simple Bed – Pillows
• Simple Bed – Square Cushion

• All files are delivered in compressed .ZIP format. You will need a third-party extraction software such as WinZip, 7-Zip, or PeaZip before using the files.
• Hybrid families combine native Revit objects with other 3D applications’ objects for a more organic and realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.
